Cutting fluid mixing equipment, produced in China, supplied in large quantities
Product Details:
| Place of Origin: | China |
| Brand Name: | Diang Tianke |
| Certification: | ISO9001 |
| Model Number: | DATK-HPQ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden case |
| Delivery Time: | 7-15 workdays |
| Payment Terms: | LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram |
| Supply Ability: | 300/month |
|
Detail Information |
|||
| Model NO.: | Datk-py | Installation: | Not Have |
|---|---|---|---|
| Centrifuge Type: | Not Have | Distillation Equipment Type: | Not Have |
| Extraction Tower Type: | Not Have | Pressure: | High Pressure |
| Condition: | New | Flow: | 1000L/H |
| Water Tank Capacity: | 120L | Compounding Concentration: | 0-50% |
| Transport Package: | Wooden Box | Trademark: | Datk |
| Origin: | China | HS Code: | 8401200000 |
| Supply Ability: | 5000 Units/Year | After-sales Service: | Life |
| Warranty: | One Year | Type: | Centrifuge |
| Object: | Cutting Fluid | Separation Mode: | Filter Type |
| Operating Type: | Continuous Type | ||
| Highlight: | China Cutting Fluid Mixing Equipment |
||
Product Description
Cutting fluid mixing equipment, produced in China, supplied in large quantities
Product Introduction
This liquid dispenser is energy-saving and environmentally friendly, does not require electricity, and has no consumables; It is an automatic mixing and mixing device that only needs to be connected to a water source to work, suitable for use in situations where the mother liquor needs to be diluted with water. Replacing manual liquid preparation, the efficiency is higher, the concentration is more uniform, and the ratio is more accurate. Easy to operate, reliable in quality, and durable.
Product parameters
| Adjustable concentration range | 0-26% | Work efficiency | Max 1500L/H |
| Working water pressure | 0.2-0.6mpa | Main material | Aluminum alloy |
| Inlet diameter | 19mm | Water outlet diameter | 25mm |
| Standard length of inlet pipe: | 2m | Standard length of water outlet pipe | 2m |
- The first step is to connect the water pipe to the inlet, pay attention to tightening the inlet to prevent water leakage, connect the outlet pipe and prepare the liquid receiving bucket;
- Step two, insert the cutting fluid bucket and fix it vertically;
- Step three, open the inlet valve;
- Step four, adjust the size of the inlet valve, measure the concentration ratio of the effluent with a refractometer, and make appropriate adjustments to achieve the normal mixing ratio;
- Step five, adjust the concentration of the regulating valve to the normal required ratio, tighten the locking nut of the regulating valve to prevent accidental touch from causing concentration changes;
- Step 6: Once the ratio is normal, automatic liquid dispensing can be performed.
About Us
Metal processing oil filtration equipment, physical purification Guangzhou Di'ang Tianke Automation Co., Ltd. specializes in the research and development, design, manufacturing, and sales of liquid tank cleaning machines, oil-water separators, cutting fluid slag removal machines, and waste liquid low-temperature evaporation equipment. The company is committed to providing comprehensive support for cleaning and environmental protection technology solutions, with a professional technical support team and over 10 years of experience in environmental protection equipment research and development.
